DAELIM S2 125

12-1
12. FRONT WHEEL/FRONT FORK/STEERING/BRAKE
SERVICE INFORMATION
GENERAL SAFETY
● Keep oil or brake fluid off the brake disk and pad because the contaminated brake disk and pad reduces the braking
performance. If contaminated, replace the pad with a new one, and clean the disk.
● Use special tire levers and rim protectors to remove or assemble tires to protect the rim from being damaged.
● Place a jack underneath the engine to support the 2-wheeled vehicle.
SPECIFICATIONS
TORQUE VALUES
STEERING STEM LOCK NUT 7.84~11.76㎏·m
STEERING TOP CONE RACE 0.49~1.27㎏f·m
FRONT SHOCK ABSORBER BOLT 1.98~2.45㎏f·m
FRONT AXLE NUT 4.41~4.9㎏f·m
BRAKE CALIPER BOLT 2.45~3.43㎏f·m
12
SERVICE INFORMATION
········
12-1
TROUBLESHOOTING
··········
12-2
STEERING HANDLE
············
12-3
FRONT WHEEL
················
12-4
FRONT WHEEL BEARING
······
12-5
SPEEDOMETER
················
12-6
FRONT WHEEL INSTALLATION
··
12-7
FRONT BRAKE
················
12-7
BRAKE FLUID
················
12-10
BRAKE CALIPER
··············
12-12
FRONT FORK
··················
12-14
STEERING STEM
··············
12-19
AXLE SHAFT RUNOUT - 0.2mm
FRONT WHEEL RIM RUNOUT
- 2.0mm
- 2.0mm
FRONT SHOCK ABSORBER SPRING FREE LENGTH 240.6mm 233mm
BRAKE DISK THICKNESS 3.8~4.2mm 3.0mm
BRAKE DISK RUNOUT - 0.30mm
TOP BRAKE CALIPER PISTON O.D. 26.94~26.97mm 26.91mm
TOP BRAKE CALIPER CYLINDER I.D. 27.00~27.05mm 27.00mm
UNDER BRAKE CALIPER PISTON O.D. 33.90~33.93mm 33.87mm
UNDER BRAKE CALIPER CYLINDER I.D. 33.96~34.01mm 34.01mm
RADICAL
AXIAL
ITEM STANDARD (mm) SERVICE LIMIT (mm)
