17-4
LIGHTS/SWITCH/HORN
HEADLIGHT BULB REPLACEMENT
● Remove the front cover.
● Remove the headlight coupler and winker coupler.
● Remove the bulb socket of rubber boots.
● Remove the rubber boots.
● Replace the headlight bulb.
FRONT WINKER BULB
REPLACEMENT
● Loosen the 2 screws, remove the winker lens.
● Replace the winker bulb.
TAILLIGHT/REAR WINKER BULB
REPLACEMENT
● Loosen the 2 screws of taillight.
● Remove the taillight lens and winker lens.
● Replace the taillight bulb and winker bulb.
•When replacing the bulb, be sure not to put finger
and contaminated gloves prints on the headlight
bulb, as they may create hot spots on the bulb and
cause is to fail.
•Note the following when replacing the bulb.
- Do not replace while the headlight is ON. After it
is turned OFF, be sure to let it cool down before
servicing.
- Wear clean gloves while replacing the bulb. Do not
put finger prints on the headlight bulb.
- If you touch the bulb with your bare hands, clean it
with a cloth moistened with alcohol and clean it
with a clean cloth again.
- Be sure to install the rubber cover after replacing
the bulb.
