DAELIM S2 125 - Windscreen; Front under Cover a; Front under Cover B

3-6
EXTERNAL PARTS
WINDSCREEN
● Remove the front cover
● Loosen the 4 washer bolts and remove the windscreen
● Install in the reverse order of removal
FRONT UNDER COVER A
● Remove the front cover and windscreen
● Loosen the 7 tapping screws securing the inner cover
● Install in the reverse order of removal
FRONT UNDER COVER B
● Loosen the 2 flange bolts
● Loosen the 4 tapping screws securing the inner cover
● Loosen the 2 washer bolts in the top of the front under
cover
● Loosen the 2 tapping screws
