13-1
13.
REAR WHEEL/BRAKE/SUSPENSION/REAR SWING ARM
SERVICE INFORMATION
GENERAL SAFETY
● If the brake drum or lining is contaminated with oil, braking power will be lost. If contaminated with oil, clean the brake
drum, and replace the brake shoe.
● Inhaled asbestos fibers have been found to cause respiratory disease and cancer. Never use an air hose or dry brush to
clean brake assemblies. Use a brake cleaner, designed to minimize the hazard caused by airborne asbestos fibers.
SPECIFICATIONS
TORQUE VALUES :
REAR CUSHION UPPER BOLT 3.5~4.5㎏f·m
REAR CUSHION LOWER BOLT 3.5~4.5㎏f·m
REAR CUSHION ROD LOCK NUT 3.0~4.5㎏f·m
REAR AXLE NUT 6.0~8.0㎏f·m
13
SERVICE INFORMATION
······
13-1
TROUBLESHOOTING
········
13-2
REAR BRAKE
·
··············
13-3
PARKING WHEEL
·
··········
13-5
REAR CUSHION
··········
·
13-7
REAR SWING ARM
········
·
13-7
ITEM STANDARD VALUE SERVICE LIMIT
AXLE SHAFT DEFLECTION - 0.2 mm
REAR WHEEL RIM WOBBLES
- 2.0 mm
- 2.0 mm
REAR BRAKE DRUM INNER DIAMETER 110.0 mm 111.0 mm
REAR BRAKE LINING THICKNESS 4.0 mm 2.0 mm
REAR CUSHION SPRING FREE LENGTH 250.8 mm 243.3 mm
RADICAL
AXIAL
