7-5
LH. CRANKCASE COVER/CONTINUOUSLY VARIABLE TRANSMISSION
● Reinstall the driven pulley on the drive shaft with the
drive belt attached.
● Hold the clutch outer using the universal holder.
Tighten the nut to the specified torque.
TORQUE VALUE : 5.0-6.0 kgf
·
m
TOOL : UNIVERSAL HOLDER
● Reinstall the LH. crankcase cover. (
)Xh
@)X?g
@V/Xg
@?V/X?f
@@@@@@@@@@@??V/Xf
@?hfV/X?e
@?hf?V/Xe
@? N1e
@? J5e
@?hf?W.Ye
@@@@@@@@@@@?eW.Y?e
@??W.Yf
@?W.Y?f
@W.Yg
@(Y?g
(Yh
7-2 )
● Remove the ramp plate, weight rollers and oil seal
from the movable drive face.
MOVABLE DRIVE FACE
REMOVAL
● Remove the LH. crankcase cover. (
)Xh
@)X?g
@V/Xg
@?V/X?f
@@@@@@@@@@@??V/Xf
@?hfV/X?e
@?hf?V/Xe
@? N1e
@? J5e
@?hf?W.Ye
@@@@@@@@@@@?eW.Y?e
@??W.Yf
@?W.Y?f
@W.Yg
@(Y?g
(Yh
7-2 )
● Hold the drive face using the drive face holder and
remove the nut.
TOOL : DRIVE FACE HOLDER
● Remove the kick starter ratchet and drive face.
● If the drive face holder cannot be used, remove the
cooling fan at the right side of the crankshaft, and hold
the flywheel with the universal holder.
TOOL : UNIVERSAL HOLDER
● Remove the drive belt. (
)Xh
@)X?g
@V/Xg
@?V/X?f
@@@@@@@@@@@??V/Xf
@?hfV/X?e
@?hf?V/Xe
@? N1e
@? J5e
@?hf?W.Ye
@@@@@@@@@@@?eW.Y?e
@??W.Yf
@?W.Y?f
@W.Yg
@(Y?g
(Yh
7-3 )
● Remove the movable drive face and drive face boss.
