DAELIM S2 125 Service Manual

1-10
SERVICE INFORMATION
SPECIFICATIONS
ITEM SPECIFICATIONS
2,110 mm
745 mm
1,356 mm
1,481 mm
760 mm
121 mm
150 kg
294 kg
Underbone
Telescopic
Swing arm
120 / 70 - 12 / Tubeless
130 / 70 - 12 / Tubeless
2.00 Kgf / ㎠
2.00 Kgf / ㎠
2.00 Kgf / ㎠
2.25 Kgf / ㎠
Hydraulic disk
Hydraulic disk
11ℓ
2.8ℓ
27。
87.1 mm
135/65 ㎠
Oil cooled / air cooled 4 cycle SOHC engine
1(Single cylinder), front angle 80。
56
×50.7 mm
124.9 ㏄
10.8 : 1
SOHC chain drive
1.1ℓAfter disassembly
0.75ℓAfter Oil change
0.8ℓAfter Oil filter change
0.9ℓAfter Oil change with Oil in the Oil hose removed
Forced pressure splash type
Paper Filter
14.0 kgf / ㎠ (550 rpm)
5。BTDC
14。ABDC
18。BBDC
1。BTDC
0.12±0.12 mm
0.12±0.12 mm
OVERALL LENGTH
OVERALL WIDTH
OVERALL HEIGHT
WHEEL BASE
SEAT HEIGHT
GROUND CLEARANCE
DRY WEIGHT
GROSS WEIGHT
TYPE
FRONT SUSPENSION / STROKE
REAR SUSPENSION / STROKE
FRONT TIRE SIZE / TYPE
REAR TIRE SIZE / TYPE
TIRE PRESSURE 1 PERSON FRONT
REAR
2 PERSON FRONT
REAR
FRONT BRAKE
REAR BRAKE
FUEL TANK CAPACITY FULL CAPACITY
RESERVE CAPACITY
CASTER ANGLE
TRAIL
FRONT FORK /REAR FORK OIL CAPACITY
TYPE
CYLINDERS / ARRANGEMENT
BORE AND STROKE
DISPLACEMENT
COMPRESSION RATIO
VALVE TRAIN
OIL CAPACITY
LUBRICATION SYSTEM
AIR CLEANER TYPE
CYLINDER COMPRESSION
INTAKE VALVE OPEN
CLOSED
EXHAUST VALVE CLOSED
CLOSED
VALVE CLEARANCE (COOLING-OFF PERIOD)
INTAKE
EXHAUST
DIMENSIONS
FRAME
ENGINE

DAELIM S2 125 Specifications

General

Displacement	124.6 cc
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air-cooled
Transmission	Automatic (CVT)
Front Brake	Disc
