DAELIM S2 125 Service Manual

1-11
SERVICE INFORMATION
ITEM SPECIFICATIONS
CV type ( vacuum ) ф25 mm
CVK 116 A
Auto-bystarter
# 102
2 and ½ trust out
20.5 mm
1.700±100 ( rpm )
Automatic Transmission
3.231 (42/13)
2.786 (39/14)
C.D.I Ignition
15。BTDC / 1.800 ( rpm )
12V 10A / 5,000 ( rpm )
Closed type (MF) 12V 10AH
CR8EH - 9 (NGK)
0.8 - 0.9 mm
15A
Starter motor
12V 55W /12V 55W
12V 5W
12V 10W
×4
12V 21 / 5W
14V 3W
14V 3W
×2
12V 2W
×2
14V 1.4W
12V 5W
TYPE / VENTURI BORE
MODEL MARK
CHOKE TYPE
MAIN JET
PILOT SCREW INITIAL SETTING
FLOAT LEVEL
IDLE SPEED
CLUTCH TYPE
PRIMARY REDUCTION
SECONDARY REDUCTION
IGNITION SYSTEM
IGNITION TIMING F MARK
AC GENERATOR CAPACITY
BATTERY TYPE / CAPACITY
SPARK PLUG
SPARK PLUG GAP
FUSE CAPACITY
STARTING SYSTEM
HEADLIGHT ( HIGH / LOW )
POSITION LIGHT
WINKER LIGHTS ( FR / RR )
TAIL / STOP LIGHT
HIGH-BEAM PILOT
WINKER PILOT
METER LIGHTS
TRUNK LAMP
LICENSE LAMP
CARBURETOR
DRIVE TRAIN
ELECTRICAL
SYSTEM

DAELIM S2 125 Specifications

General

Displacement	124.6 cc
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air-cooled
Transmission	Automatic (CVT)
Front Brake	Disc
