SERVICE INFORMATION
GENERAL SAFETY
● The starter motor can be maintained without removing the engine from the vehicle.
● A weak battery may be unable to turn the starter motor quickly enough, or, supply adequate ignition current.
● The starter motor may be damaged if current is allowed to flow to it when the engine cannot turn over.
● The engine may not be turned over if the stop switch is faulty.
SPECIFICATION
16-1
·Always turn the ignition switch OFF before servicing the starter motor. The moter could suddenly start, causing
serious injury.
16. STARTER SYSTEM
16
SERVICE INFORMATION
········
16-1
STARTER DEVICES LOCATION
··
16-2
TROUBLESHOOTING
··········
16-3
STARTER MOTOR
············
16-4
STARTER MAGNETIC SWITCH
··
16-7
ITEM
STARTER MOTOR BRUSH LENGTH
STANDARD VALUE
10.2 mm
SERVICE LIMIT
5 mm
TOOLS
DIGITAL TESTER
VERNIER CALIPER
