DAELIM S2 125

5-5
FUEL SYSTEM
FLOAT CHAMBER/FLOAT/JET
DISASSEMBLY
● Loosen the 4 screws securing the float body.
● Remove the float pin, float, and float value.
● Check the float valve and valve seat for scores, scratches,
clogging and damage. Replace if necessary.
● Check the float valve operation.
● Remove the main jet, main jet holder, holder washer,
jet screw, jet washer, needle jet, slow jet, pilot jet,
washer and O-ring.
•Turn in the pilot jet and record the number of turns it
takes before it seats lightly.
•Do not force the pilot screw against its seat ;
the seat will be damaged.
