Figure 4-64 OSD information
Step 2 Congure OSD information.
Table 4-19 Description of OSD information
Parameter
Description
Preset
Select Enable, and the preset name is displayed in the image when the
camera turns to the preset, and it will disappear 3 s later.
Temperature
Select Enable and the internal temperature of the current device is
displayed.
Coordinates Select Enable and the PTZ coordinates info is displayed in the image.
Zoom
Select Enable and the zoom info is displayed in the image. Such as
, which means 12x zoom rate.
North Select Enable and the north direction is displayed in the image.
RS485 Select Enable and it will enable RS-485 communication function.
Text
Select Enable and set text, and the text is displayed in the image.
Input Text
Text Align Alignment mode of the displayed information in the image.
Step 3 Move the OSD box to the position that you want in the image.
Step 4 Click Save.
4.5.2.3.9 Conguring Counting
The image displays statistics of the enter number and leave number. When the overlay function is
enabled during intelligent rules conguration, this function is enabled simultaneously.
Operation Manual
74
