81
4.2.8.2 Firmware
It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input,
external alarm and etc. See Figure 4-50.
Figure 4-50
4.3 Preview
After device booted up, the system is in multiple-channel display mode. See Figure 4-51.Please note the
displayed window amount may vary. The following figure is for reference only. Please refer to chapter 1.3
Specifications for the window-amount your product supported.
Figure 4-51
4.3.1 Preview
If you want to change system date and time, you can refer to general settings (Main
Menu->Setting->System->General). If you want to modify the channel name, please refer to the
display settings (Main Menu->Camera->CAM name)
Please refer to the following sheet for detailed information.
When current channel is recording, system displays this icon.
To Next Page
