Dahua NVR5432-XI User Manual

User's Manual
97
Figure 3-33 Take out HDD box
Step 2 Put the HDD into the HDD box along the direction shown in the following arrow.
Figure 3-34 Put HDD into box
Step 3 Fasten the screws on the sides of the HDD box.
Figure 3-35 Fasten screws
Step 4 Insert the HDD box into the HDD slot, press it to the bottom, and then close the box
handle.

Dahua NVR5432-XI Specifications

General

Brand	Dahua
Model	NVR5432-XI
Category	Network Hardware
Language	English
