Figure 2-36 Front panel
2.2 Rear Panel
2.2.1 NVR21-4KS2/NVR21-P-4KS2/NVR21-8P-4KS2/
NVR21-4KS3/NVR21-P-4KS3/NVR21-8P-4KS3/NVR41-EI/
NVR41-8P-EI/NVR41-P-EI/NVR41-4KS3/NVR41-P-4KS3/
NVR41-8P-4KS3 Series
The NVR21-4KS2/NVR21-4KS3/NVR41-EI//NVR41-4KS3 is shown as below.
Figure 2-37 Rear panel
The NVR41-P-EI/NVR21-P-4KS2/NVR21-P-4KS3/NVR41-P-4KS3 is shown as below.
Figure 2-38 Rear panel
The NVR21-8P-4KS2/NVR21-8P-4KS3/NVR41-8P-EI/NVR41-8P-4KS3 is shown as below.
