User's Manual
287
when the staying period exceeds the defined duration, an alarm is triggered.
Procedure
Step 1 Select
Main Menu
>
AI
>
Parameters
>
People Counting
>
People Counting
.
Figure 5-178 People counting
Step 2 Select a channel, and then click
Add
.
Step 3 Select the
Enable
checkbox, and then set
Type
to
In Area No.
Step 4 Draw people counting rule.
1) Click to draw a rule. Right-click the image to stop drawing.
2) Configure the parameters.
3) Click
OK
.
Step 5 Click and then enable in-area people number alarm and stay alarm.
Step 6 Click under
Trigger
to configure the alarm schedule and linkage. For details on alarm
linkage, see Table 5-50.
Step 7 Click
Apply
.
5.9.12.4 Configuring Queuing
After configuring queuing alarm, the system can realize the corresponding linkage actions once the
number of people in the queue or the waiting time has triggered an alarm.
Procedure
Step 1 Select
Main Menu
>
AI
>
Parameters
>
People Counting
>
Queuing
.
