User's Manual
290
Figure 5-182 Custom
2. Configure parameters.
Table 5-49 Parameters description
Parameters Description
Sensitivity
The default is 5. The higher the sensitivity, the
more sensitive the detection will be.
Although there are more targets captured in
the same scene, false detections occur.
Min Duration
Set the minimum time for the crowding in the
detection area until an alarm is triggered.
Repeat Alarm Time
Set the repeat alarm time.
If the alarm state persists, when reaching the
repeat alarm time, the alarm is triggered again.
If the alarm is triggered for less than the set minimum duration, the alarm cannot be
established.
Step 6 Click under
Trigger
to configure alarm schedule and linkage. For details on alarm
linkage, see Table 5-50.
Step 7 Click
Apply
.
5.9.12.6 Report Query
Background Information
You can search for and export the people counting statistics.
