5.7.5.2 Privacy Masking
You can mask certain areas of the video image for privacy protection.
Procedure
Step 1 Select Main Menu > CAMERA > Overlay > Privacy Masking.
Figure 5-71 Privacy masking
Step 2 Select a channel.
Step 3 Click to enable privacy masking.
Step 4 Click Add, select the masking type and color, and then draw mosaic or color blocks in the
image as needed.
A masking block appears on the video image.
●
The number of masking blocks that you can add might dier depending on the
camera. You can add up to 24 masking blocks.
●
Click Clear to delete all masking areas. Click
to delete a masking area.
Step 5 Drag the masking block to a desired position and then congure the type, color and other
parameters.
Step 6 Click Apply.
5.7.6 Conguring Encoding Settings
You can set video bit stream and image parameters.
User's Manual
194
