User's Manual
162
●
The different installations modes have different de-warp modes.
●
Some models support de-warp of 180° fisheye camera. 180° fisheye camera supports de-warp in
wall mount mode only.
Figure 5-56 Fisheye settings
Table 5-16 Installation mode
Installation mode Icon Description
(Ceiling mount)
(Ground mount)
360° panorama original view
1 de-warp window+1 panorama stretching
2 panorama stretching views
1 360° panorama view+3 de-warp windows
1 360°panorama view+4 de-warp windows
4 de-warp windows+1 panorama stretching
1 360° panorama view+8 de-warp windows
(Wall mount)
360°panorama original view
Panorama stretching
1 panorama unfolding view+3 de-warp
windows
1 panorama unfolding view +4 de warp
windows
1 panorama unfolding view +8 de warp
windows
