Figure 5-132 IVS

Step 2 Select the channel and AI type.

Step 3 Click

Add

to add a rule.

Step 4 On the

Type

list, select

Tripwire

Step 5 Draw the detection rule.

1) Click to draw a straight line or a curve on the surveillance video image. Right-click

the image to stop drawing.
