User's Manual
349
Figure 5-236 SNMP
Step 2 Click to enable the function.
Step 3 Configure the parameters.
Table 5-68 SNMP parameters
Parameter Description
Version
Select the checkbox of SNMP version that you are using.
The default version is
V3
. There is a risk if you use V1 or V2.
SNMP Port Enter the monitoring port on the agent program.
Read Community
Enter the read and write strings supported by the agent program.
Write Community
Trap Address
Enter the destination address for the agent program to send the Trap
information.
Trap Port
Enter the destination port for the agent program to send the Trap
information.
Read-Only
Username
Enter the username that is allowed to access the Device and has the
read-only permission.
Read/Write
Username
Enter the username that is allowed to access the Device and has the read
and write permission.
