User's Manual

368

Figure 5-255 Record estimation

Step 2 Click .

You can configure the

Resolution

Frame Rate

Bit Rate

and

Record Time

for the selected

channel.

Figure 5-256 Modify channel settings

Step 3 Click

Apply

Then the system will calculate the time period that can be used for storage according to

the channels settings and HDD capacity.
