Control Panel
■About monitoring target and operation (a) (b) (c) settings
* To avoid a temperature range warning during setting, input the following items (d) and (e) before setting (a), (b)
and (c).
(1) Set the “temperature range warning temperature (d)” with “monitoring target (a)” and “comparison target (b)”
based on the following formula.
Settings for monitoring target (a)
Settings for comparison target (b)
≥(*1)
Temperature range warning temperature (d)
*1: When the setting No. of comparison target (b) is 5 or 6, it becomes “≥ fixed value” or “≤ fixed value”.
(2) Set “operation at time of warning (c)”.
*
2: The machine temperature tuning thermistor
option is required.
*3: Use this setting No. also for the returned oil
temperature thermistor option.
*4: Output to the external terminal follows the parameter setting n001 in accordance with page 66.
Operation mode after temperature range warning is activated (c)
Setting
No.
Settings
0
(Without using the warning function)
1
Machine temperature (Th-1) *2
2
Outlet oil temperature (Th-2) *3
3
Room temperature (Th-3)
4
Inlet oil temperature (Th-4)
Setting
No.
Settings
0
(Without using the warning function)
1
2
3
4
5
6
-Outlet oil temperature (Th-2)
-Room temperature (Th-3)
-Inlet oil temperature (Th-4)
≥ fixed value
≤ fixed value
-Machine temperature (Th-1)
Setting
No.
0
1
2
3
4
5
Output
No output
Output
No output
Output
External output (*4)
Terminal [60]-[61]/[60]-[63] Terminal [66]-[67]
No output
Output
Operation
Compressor
only
forced stop
Automatic reset
Manual reset
(power supply is
turned ON again)
Display Compressor start/stop and reset method
(Without using the warning function)
Warning
(1E to 5E)
display
Alarm
(F1 to F5)
display
Monitoring target (a) Comparison target (b)
(a) (b) (c)
