Functions
Function Description
5
(Reference)
Running
condition
in normal
status
Temperature
and pressure of
respective sections
The table below shows the guideline of temperatures and pressures during
normal running.
Unit: ℃
Standard point (room temperature/
oil temperature=35/35℃)
Capacity command value=100%
Reference point (room temperature/
oil temperature=25/25℃)
Capacity command value=10%
Th-6 Th-7 Th-8 LP
☆ 1
(MPa) Th-6 Th-7 Th-8 LP
☆ 1
(MPa)
AKZ14A-500 76 53 14 1.01 33 27 20 1.35
AKZ32A-500 81 54 18 1.01 42 26 12 1.02
AKZ43A-500 80 56 22 1.08 40 27 13 1.10
AKZ56A-500 91 54 10 0.95 42 27 15 1.12
AKZ90A-500 74 53 5 0.71 50 27 8 0.82
*1 Temperatures and pressures above are measured under the conditions
shown below. Power supply: 200 V (50Hz), oil used: VG32, pump
discharge pressure: 0.2MPa, clean air filter and compressor are used.
*2 For pressure measurement of ☆1, connection of a pressure gauge to
the low-pressure gauge port is required.
Current value of
respective functional
parts
The table below shows the guideline of output current values of respective
functional parts during normal running.
Unit: A
Power supply Pump Compressor DC fan
AKZ14A
200V (50Hz) 1.3
2.5 0.13
200V (60Hz) 1.1
AKZ32A
200V (50Hz) 1.4
3.7 0.27
200V (60Hz) 1.2
AKZ43A
200V (50Hz) 1.4
5.0 0.27
200V (60Hz) 1.2
AKZ56A
200V (50Hz) 2.7
5.3 0.37
200V (60Hz) 2.2
AKZ90A
200V (50Hz) 2.7
10.3 0.55
200V (60Hz) 2.2
Power supply Pump Compressor DC fan
AKZ14A-500
400V (50Hz) 0.38
1.4 0.05
400V (60Hz) 0.25
AKZ32A-500
400V (50Hz) 0.42
2.1 0.10
400V (60Hz) 0.35
AKZ43A-500
400V (50Hz) 0.42
2.6 0.10
400V (60Hz) 0.35
AKZ56A-500
400V (50Hz) 0.84
2.9 0.12
400V (60Hz) 0.70
AKZ90A-500
400V (50Hz) 0.84
6.6 0.30
400V (60Hz) 0.70
*1 Current values above are measured under the conditions shown below.
Oil used: VG32, outside of unit pressure loss: 0, pump discharge
pressure: 0.2MPa, clean air filter and condenser are used.
*2 Respective parts have variation between the legs. Use the table as the
guide of intermediate values of the phases.
