SUBCOOLING = (SAT. LIQUID TEMP.) - (LIQUID LINE
TEMP.)
Charging Table
OD Ambient
Temp (degF)
< 65 °F 65°F to 105°F > 105 °F
Subcooling
(degF)
Weigh in
Charge
1.5 T - 10 ±1°F
2.0 T - 12 ±1°F
2.5 T - 14 ±1°F
3.0 T - 14 ±1°F
3.5 T - 10 ±1°F
4.0 T - 8 ±1°F
5.0 T - 9 ±1°F
Weigh in
Charge
Note: Subcooling information is valid only while the unit is operating at
100% capacity or 100% of compressor speed in CHARGE MODE.
Compressor speed is displayed under STATUS menu in the thermostat.
NOTE: Not more than 3/8 lb. (6 oz.) of refrigerant be added
to the system at a time to achieve the target subcooling. It
is recommended adding 1 oz. refrigerant each time, then
wait 10 minutes to stabilize the system.
check the Schrader portS for leakS and tIghten ValVe coreS, If
neceSSary. InStall capS fInger-tIght.
NOTICE
do not adjuSt the charge BaSed on SuctIon preSSure.
NOTICE
SATURATED LIQUID
PRESSURE TEMPERATURE
CHART
SATURATED LIQUID
PRESSURE TEMPERATURE
CHART
LIQUID
PRESSURE
PSIG
R-410A
°F
LIQUID
PRESSURE
PSIG
R-410A
°F
200 70 325 101
210 73 355 108
220 76 375 112
225 78 405 118
235 80 415 119
245 83 425 121
255 85 435 123
265 88 445 125
275 90 475 130
285 92 500 134
295 95 525 138
305 97 550 142
heat pump WIth outdoor temperature
lockoutS
It is recommended to set the outdoor temperature lockouts
during the initial thermostat set up. Compressor lockout
temperature will enable the compressor to be turned off and
switch heating source from refrigeration to auxiliary/secondary
heating under low outdoor ambient conditions.
In case of 30 ft. or longer line set application, refrigerant may
be accumulated inside line set pipe. Select 15°F or higher
compressor (heat pump) lockout temperature to set heat
pump lockout.
Backup heat lockout temperature will enable auxiliary/sec-
ondary heating to be turned on when outdoor temperature
is much higher than indoor temperature, compressor might
stop operating under this circumstance.
