7-Segment dISplay
SCREEN 0 (Display FAULT CODE)
Setting
No.
Contents Notes
1 Fault code (present)
SCREEN 1 (Display FAULT CODES)
Setting
No.
Contents Notes
1 Fault code (latest) Latest
2 Fault code (2nd) 2nd
3 Fault code (3rd) 3rd
4 Fault code (4th) 4th
5 Fault code (5th) 5th
6 Fault code (6th) 6th
SCREEN 2 (MONITOR MODE)
Setting
No.
Contents Notes
1 Compressor operation time unit: hr (Multiply by 200)
2 Operation code
0: Stop
1: Cooling Start-up
2: Heating Start-up
3: Oil Return Operation
4: Heating Operation
5: Defrost Operation
6: Cooling Operation
3 Compressor Reduction Mode 0:OFF, 1: ON
4 % Demand
unit: %
(Cut off the decimal rst place)
5 Act % demand
unit: %
(Cut off the decimal rst place)
6 Requested ID CFM unit: CFM (Multiply by 10)
7 Reported ID CFM unit: CFM (Multiply by 10)
8 Outdoor FAN RPM unit: RPM (Multiply by 10)
9 Ta (Outdoor Air Temperature) unit: F
10 Td (Discharge Temperature) unit: F
11 Tm (Outdoor Coil Temperature) unit: F
12 Tb (Defrost Sensor Temperature) unit: F
13 Tl (Liquid Temperature) unit: F
14 Pressure Sensor unit: PSI
15 Ts (Suction Temperature) unit: F
