7-Segment dISplay
SCREEN 3 (SETTING MODE 1)
Setting No. Contents Setting Installer/Serviceman Notes
1 Cool Airow Trim High*
1
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
2 Cool Airow Trim Int
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
3 Cool Airow Trim Low
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
4 Cool Prole
0:A
1:B
2:C
3:D
5 Cool Fan ON Delay
0:5sec.
1:10sec.
2:20sec. 3:30sec.
6 Cool Fan OFF Delay
0:30sec.
1:60sec.
2:90sec. 3:120sec.
7 Dehumidication Select
0:ON 1:OFF
8 Heat Airow Trim High
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
9 Heat Airow Trim Int
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
10 Heat Airow Trim Low
0:-15%
1:-12%
2:-9%
3:-6%
4:-3%
5:0%
6:3%
7:6%
8:9%
9:12%
10:15%
11 Heat Fan ON Delay
0:5sec. 1:10sec. 2:15sec.
12 Heat Fan OFF Delay
0:30sec.
1:50sec.
2:70sec. 3:90sec.
SCREEN 4 (SETTING MODE 2)
Setting No. Contents Setting Installer/Serviceman Notes
1 Maximum Defrost Interval
0: 30min.
1: 60min.
2: 90min.
3: 120min.
2 Set Maximum Current N/A Future Use
3 Vertical Rise
0:Same Level
1:Outdoor Lower
2:Indoor Lower
4 System Verication Test 0:ON
1:OFF
