COOL SETUP
SUBMENU ITEM USER MODIFIABLE OPTIONS COMMENTS
CL Reset YES or NO Selecting to default factory setting.
Cool Airow Trim Hi
*
1
-15% to +15% in 3% increments Selects the cooling airow trim amount.
Cool Airow Trim Int -15% to +15% in 3% increments Selects the cooling airow trim amount.
Cool Airow Trim Low -15% to +15% in 3% increments Selects the cooling airow trim amount.
Cool Airow Prole A, B, C, or D Selects the cooling airow prole.
Cool ON Delay 5, 10, 20, 30 seconds Selects the indoor blower ON delay.
Cool OFF Delay 30, 60, 90, 120 seconds Selects the indoor blower OFF delay.
Dehumidication Select ON or OFF
Selecting “OFF” disables dehumidication; selecting
“ON” enables dehumidication.
SET COOLING RUN VALUES (CL RUN VALUES)
SUBMENU ITEM USER MODIFIABLE OPTIONS COMMENTS
Maximum Compressor RPS Range
for Cooling
(COOL RPS RANGE)
Five different compressor RPS
ranges will be provided.
Select the appropriate range for the installed system
conguration.
Maximum Compressor RPS Selec-
tion for Cooling
(COOL RPS SELECT)
10 compressor RPS values will be
provided within the range selected
in the COOL RPS RANGE menu.
Select the appropriate compressor RPS for the
installed system conguration.
HEAT SETUP
SUBMENU ITEM USER MODIFIABLE OPTIONS COMMENTS
HT Reset YES or NO Selecting to default factory setting.
Heat Airow Trim Hi -15% to +15% in 3% increments Selects the Heating airow trim amount.
Heat Airow Trim Int -15% to +15% in 3% increments Selects the Heating airow trim amount.
Heat Airow Trim Low -15% to +15% in 3% increments Selects the Heating airow trim amount.
Heat ON Delay 5, 10, 15 seconds Selects the indoor blower ON delay.
Heat OFF Delay 30, 50, 70, 90 seconds Selects the indoor blower OFF delay.
Maximum Defrost Interval 30 mins., 1 hr., 1.5 hrs. & 2 hrs. Selects time defrost interval
SET HEATING RUN VALUES (HT RUN VALUES)
SUBMENU ITEM USER MODIFIABLE OPTIONS COMMENTS
Maximum Compressor RPS Range
for Heating
(HEAT RPS RANGE)
Five different compressor RPS
ranges will be provided.
Select the appropriate range for the installed system
conguration.
Maximum Compressor RPS Selec-
tion for Heating
(HEAT RPS SELECT)
10 compressor RPS values will be
provided within the range selected
in the HEAT RPS RANGE menu.
Select the appropriate compressor RPS for the
installed system conguration.
*
1
Depending on the connected Indoor unit, there are restrictions on the positive side Trim setting.
If you want to change the Cool Airow Trim to positive side, be sure to conrm the Airow Trim restrictions in the latest Indoor unit Installation Manual.
The latest Manual can be obtained from the website “DAIKIN CITY (Installation Manual/Unitary Split System)” or “PartnerLink (Info-
FinderPlus/Literature)”.
