Indoor Unit SiBE06-708_A
137 Removal Procedure
1. Indoor Unit
1.1 Removal of Air Filter / Front Panel / Front Grille
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1. External appearance
2
. Remove the front panel.
(R6768)

Slide the right and the left
hooks to the center.
1 Unfasten the 2 hooks
on the top of the front
panel.
Operation lamp Timer lamp
(R6766)
Indoor Unit ON /
OFF button
Front panel
(R6767)
