SiBE06-708_A Printed Circuit Board Connector Wiring Diagram
Printed Circuit Board Connector Wiring Diagram 22
1.2 Outdoor Unit
1.2.1 RK(X)S25/35F2V1B
Connectors and
Other Parts
PCB (1): Filter PCB
PCB (2): Main PCB
1) S11 Connector for main PCB
2) HL1, HN1, S Connector for terminal board
3) E Terminal for earth
4) HC1, HC2
HL2, HN2
Connector for main PCB
5) HR1 Connector for reactor
6) FU3 Fuse (20 A, 250 V)
7) V2, V3 Varistor
1) S10 Connector for filter PCB
2) S20 Connector for electronic expansion valve coil
3) S30 Connector for compressor
4) S40 Connector for overload protector
5) S70 Connector for fan motor
6) S80 Connector for four way valve coil
7) S90 Connector for thermistors
(outdoor temperature, outdoor heat exchanger, discharge pipe)
8) HC3, HC4
HL3, HN3
Connector for filter PCB
9) HR2 Connector for reactor
10)FU1, FU2 Fuse (3.15 A, 250 V)
11)LED A LED for service monitor (green)
12)V1 Varistor
13)J5 Jumper for improvement of defrost performance
∗
Refer to page 261 for detail.
14)J8 Jumper for facility setting
∗
Refer to page 260 for detail.
