Daikin Floor Standing Type F-Series User Manual

Specifications SiBE06-708_A
9 Specifications
1. Specifications
1.1 Cooling Only
Note:

The data are based on the conditions shown in the table below.

SL : The quiet fan level of the airflow rate setting.
50 Hz, 220 - 230 - 240 V
Model
Indoor Units FVXS25FV1B FVXS35FV1B
Outdoor Units RKS25F2V1B RKS35F2V1B
Capacity
Rated (Min. ~ Max.)
kW 2.5 (1.3 ~ 3.0) 3.5 (1.4 ~ 3.8)
Btu/h 8,500 (4,400 ~ 10,200) 11,900 (4,800 ~ 13,000)
kcal/h 2,150 (1,120 ~ 2,580) 3,010 (1,200 ~ 3,270)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 3.5 - 3.3 - 3.2 4.9 - 4.7 - 4.5
Power Consumption
Rated (Min. ~ Max.)
W 570 (300 ~ 920) 1,020 (300 ~ 1,250)
Power Factor % 74.0 - 75.1 - 74.2 94.6 - 94.4 - 94.4
COP (Rated) W/W 4.39 3.43
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
20.0
φ
20.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FVXS25FV1B FVXS35FV1B
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 8.2 (290) 8.5 (300)
M 6.5 (229) 6.7 (237)
L 4.8 (169) 4.9 (174)
SL 4.1 (146) 4.5 (158)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.14 - 0.13 - 0.12 0.14 - 0.13 - 0.12
Power Consumption W 15 15
Power Factor % 48.7 - 50.2 - 52.1 48.7 - 50.2 - 52.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 600 × 700 × 210 600 × 700 × 210
Packaged Dimensions (H × W × D) mm 696 × 786 × 286 696 × 786 × 286
Weight kg 14 14
Gross Weight kg 18 18
Operation
Sound
H / M / L / SL dBA 38 / 32 / 26 / 23 39 / 33 / 27 / 24
Sound Power dBA 54 55
Outdoor Unit RKS25F2V1B RKS35F2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.0 1.0
Airflow Rate m³/min (cfm)
H 33.5 (1,183) 33.5 (1,183)
L 23.4 (826) 23.4 (826)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current A 3.4 - 3.2 - 3.1 4.8 - 4.6 - 4.4
Power Consumption W 555 1,005
Power Factor % 74.2 - 75.4 - 74.6 95.1 - 95.0 - 95.1
Starting Current A 3.5 4.9
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H / L dBA 46 / 43 47 / 44
Sound Power H dBA 61 62
Drawing No. 3D056295A 3D056296A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
7.5 m
