Indoor Unit SiBE06-708_A
139 Removal Procedure
5 Release the string from
the hook.
Lift up the front panel to
unfasten the 3 hooks at
the bottom and then
remove the front panel.
6 When installing the air
filter, catch the 2 hooks
at the bottom.
When installing the
front panel, catch the 3
hooks of the front grille
and hook the string to
prevent the front panel
from dropping.
7 Remove the 4 screws
from the front grille.
Step Procedure Points
Hooks for the air filter
Hooks for the front panel
Front grille
(R6773)
To Next Page
