Table 19 continued: Group 36: Timed Functions
3603 STOP TIME 1 00:00:00…23:59:58 2 s 12:00:00 AM
Denes the daily stop time.
• The time can be changed in steps of 2 seconds.
• If the parameter value is 09:00:00, the timer is deactivated at 9 a.m.
3604 START DAY 1 1…7 1 1 (MONDAY)
Denes the weekly start day.
1 = MONDAY…7 = SUNDAY
• If parameter value is 1, timer 1 weekly is active from Monday midnight (00:00:00).
3605 STOP DAY 1 1…7 1 1 (MONDAY)
Denes weekly stop day.
1 = MONDAY…7 = SUNDAY
• If parameter value is 5, timer 1 weekly is deactivated on Friday midnight (23:59:58).
3606 START TIME 2 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer2 daily start time.
• See parameter 3602.
3607 STOP TIME 2 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer 2 daily stop time.
• See parameter 3603.
3608 START DAY 2 1…7 1 1 (MONDAY)
Denes timer 2 weekly start day.
• See parameter 3604.
3609 STOP DAY 2 1…7 1 1 (MONDAY)
Denes timer 2 weekly stop day.
• See parameter 3605.
3610 START TIME 3 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer 3 daily start time.
• See parameter 3602.
3611 STOP TIME 3 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer 3 daily stop time.
• See parameter 3603.
3612 START DAY 3 1…7 1 1 (MONDAY)
Denes timer 3 weekly start day.
• See parameter 3604.
3613 STOP DAY 3 1…7 1 1 (MONDAY)
Denes timer 3 weekly stop day.
• See parameter 3605.
3614 START TIME 4 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer 4 daily start time.
• See parameter 3602.
3615 STOP TIME 4 00:00:00…23:59:58 2 s 12:00:00 AM
Denes timer 4 daily stop time.
• See parameter 3603.
3616 START DAY 4 1…7 1 1 (MONDAY)
Denes timer 4 weekly start day.
• See parameter 3604.
3617 STOP DAY 4 1…7 1 1 (MONDAY)
Denes timer 4 weekly stop day.
• See parameter 3605.
3622 BOOSTER SEL -6…6 1 0 (NOT SEL)
Selects the source for the booster signal.
0 = NOT SEL – Booster signal is disabled.
1 = DI1 – Denes DI1 as the booster signal.
2…6 = DI2…DI6 – Denes DI2…DI6 as the booster signal.
-1 = DI1(INV) – Denes an inverted digital input DI1 as the booster signal.
-2…-6 = DI2(INV)…DI6(INV) – Denes an inverted digital input DI2…DI6 as the booster signal.
3623 BOOSTER TIME 00:00:00…23:59:58 2 s 00:00:00
Denes the booster ON time. Time is started when booster sel signal is released. If parameter value is 01:30:00, booster is active for 1 hour and 30 minutes
after activation DI is released.
