Group 01: Operating Data
This group contains drive operating data, including actual signals. The drive sets the values for actual signals, based on
measurements or calculations. You cannot set these values.
Table 5: Group 01: Operating Data
Code Description Range Resolution Default S
0101 SPEED & DIR
-30000…
30000 rpm
1 rpm —
The calculated signed speed of the motor (rpm). The absolute value of 0101 SPEED & DIR is the same as the value of 0102 SPEED.
• The value of 0101 SPEED & DIR is positive if the motor runs in the forward direction.
• The value of 0101 SPEED & DIR is negative if the motor runs in the reverse direction.
0102 SPEED
0…30000
rpm
1 rpm —
The calculated speed of the motor (rpm).
0103 OUTPUT FREQ
0.0…500.0
Hz
0.1 Hz —
The frequency (Hz) applied to the motor.
0104 CURRENT
0.0…1.5
× I2
n
0.1 A —
The motor current, as measured by the MD5.
0105 TORQUE
-200.0…
200.0%
0.1% —
Output torque. Calculated value of torque on motor shaft in % of motor nominal torque.
0106 POWER
-1.5…1.5
× P
n
0.1 kW —
The measured motor power in kW.
0107 DC BUS VOLTAGE
0…2.5 ×
VdN
1 V —
The DC bus voltage in V DC, as measured by the MD5.
0109 OUTPUT VOLTAGE
0…2.0 ×
V
dN
1 V —
The voltage applied to the motor.
0110 DRIVE TEMP
0.0…150.0
°C
0.1 °C —
The temperature of the drive power transistors in degrees Celsius.
0111 EXTERNAL REF
1
0.0…500.0
Hz /
0…30000
rpm
0.1 Hz / 1
rpm
—
External reference, REF1, in rpm or Hz – units determined by parameter 9904.
0112 EXTERNAL REF 2
0.0…100.0%
(0.0…600.0%
for torque)
0.1% —
External reference, REF2, in %.
0113 CTRL LOCATION 0…2 1 —
Active control location. Alternatives are:
0 = LOCAL
1 = EXT1
2 = EXT2
0114 RUN TIME (R) 0…9999 h 1 h —
The drive’s accumulated running time in hours (h).
• Can be reset by pressing UP and DOWN keys simultaneously when the control panel is in the Parameters mode.
0115 KWH COUNTER (R
0…65535
kWh
1 kWh —
The drive’s accumulated power consumption in kilowatt hours.
• The counter value is accumulated till it reaches 65535 after which the counter rolls over and starts again from 0.
• Can be reset by pressing UP and DOWN keys simultaneously when the control panel is in the Parameters mode. MD5-UH User’s Manual 1-83 Parameters
0116 APPL BLK OUTPUT
0.0…100.0%
(0.0…600.0%
for torque)
0.1% —
Application block output signal. Value is from either:
• PFA control, if PFA Control is active, or
• Parameter 0112 EXTERNAL REF 2.
