TeChniCal daTa
Ratings
By type code, the table below provides ratings for the MD5
adjustable speed AC drive, including:
• IEC ratings
• NEMA ratings (shaded columns)
• Frame size
Ratings, 208…240 volt drives
Abbreviated column headers are described in Symbols on
page 83.
Table 58: Ratings, 208…240 volt drives
Valid up to 40°C (104 °F)
Frame Size
I2
n
A
P
n
HP
Three-phase supply voltage, 208…240 V
4.6 1.0 R1
6.6 1.5 R1
7.5 2.0 R1
11.8 3.0 R1
16.7 5.0 R1
24.2 7.5 R2
30.8 10.0 R2
46.2 15.0 R3
59.4 20.0 R3
74.8 25.0 R4
88.0 30.0 R4
114 40.0 R4
143 50.0 R6
178 60.0 R6
221 75.0 R6
248 100 R6
Ratings, 380…480 volt drives
Abbreviated column headers are described in Symbols on
page 83.
Table 59: Ratings, 380…480 volt drives
Valid up to 40°C (104 °F)
Frame Size
I2
n
A
P
n
HP
Three-phase supply voltage, 380…480 V
3.3 1.5 R1
4.1 2 R1
6.9 3 R1
8.8 5 R1
11.9 7.5 R1
15.4 10 R2
23 15 R2
31 20 R3
38 25 R3
44 30 R3
44 30 R4
59 40 R4
72 50 R4
77 60 R4
96 75 R4
77 60 R5
96 75 R5
124 100 R5
