BACnet Protocol Technical Data
Binary Input Object Instance Summary
The following table summarizes the Binary Input Objects supported:
Table 37: Binary Input Objects
Instance ID Object Name Description Active/Inactive Text Present Value Access Type
BI0 RO 1 ACT This object indicates the status of Relay Output 1. ON/OFF R
BI1 RO 2 ACT This object indicates the status of Relay Output 2. ON/OFF R
BI2 RO 3 ACT This object indicates the status of Relay Output 3. ON/OFF R
BI3 RO 4 ACT This object indicates the status of Relay Output 4 (requires OREL-01 option). ON/OFF R
BI4 RO 5 ACT This object indicates the status of Relay Output 5 (requires OREL-01 option) ON/OFF R
BI5 RO 6 ACT This object indicates the status of Relay Output 6 (requires OREL-01 option) ON/OFF R
BI6 DI 1 ACT This object indicates the status of Digital Input 1. ON/OFF R
BI7 DI 2 ACT This object indicates the status of Digital Input 2. ON/OFF R
BI8 DI 3 ACT This object indicates the status of Digital Input 3. ON/OFF R
BI9 DI 4 ACT This object indicates the status of Digital Input 4. ON/OFF R
BI10 DI 5 ACT This object indicates the status of Digital Input 5. ON/OFF R
BI11 DI 6 ACT This object indicates the status of Digital Input 6. ON/OFF R
NOTE: For Present Value Access Types, R = Read-only,
W = Writeable, C = Commandable. Commandable
values support priority arrays & relinquish defaults.
Binary Output Object Instance Summary
The following table summarizes the Binary Output Objects supported:
Table 38: Binary Output Objects
Instance ID Object Name Description Active/ Inactive Text Present Value Access Type
BO0 RO1 COMMAND
This object controls the output state of Relay 1. This control requires that
parameter 1401 value = COMM.
ON/OFF C
BO1 RO2 COMMAND
This object controls the output state of Relay 2. This control requires that
parameter 1402 value = COMM.
ON/OFF C
BO2 RO3 COMMAND
This object controls the output state of Relay 3. This control requires that
parameter 1403 value = COMM.
ON/OFF C
BO3 RO4 COMMAND
This object controls the output state of Relay 4. This control requires that
parameter 1410 value = COMM (also requires OREL-01 option).
ON/OFF C
BO4 RO5 COMMAND
This object controls the output state of Relay 5. This control requires that
parameter 1411 value = COMM (also requires OREL-01 option).
ON/OFF C
BO5 RO6 COMMAND
This object controls the output state of Relay 6. This control requires that
parameter 1412 value = COMM (also requires OREL-01 option).
ON/OFF C
NOTE: For Present Value Access Types, R = Read-only,
W = Writeable, C = Commandable. Commandable
values support priority arrays & relinquish defaults.
eMbedded fieldbUs
www.DaikinApplied.com 59 OM 1191 • MD5 VFD
