Feedback from the Drive – EFB
Pre-Dened Feedback
Inputs to the controller (drive outputs) have pre-dened
meanings established by the protocol. This feedback does not
require drive conguration. The following table lists a sample of
feedback data.
NOTE: With Modbus, any parameter can be accessed using
the format: 4 followed by the parameter number.
Table 33: Pre-Dened Feedback
Drive Parameter
Protocol Reference
Modbus N2 FLN BACnet
0102 SPEED 40102 AI3 5 AV0
0103 FREQ OUTPUT 40103 AI1 2 AV1
0104 CURRENT 40104 AI4 6 AV4
0105 TORQUE 40105 AI5 7 AV5
0106 POWER 40106 AI6 8 AV6
0107 DC BUS VOLT 40107 AI11 13 AV2
0109 OUTPUT VOLTAGE 40109 AI12 14 AV3
0115 KWH COUNTER 40115 AI8 10 AV8
0118 DI1-3 STATUS – bit 1 (DI3) 40118 BI10, BI11, BI12, 70, 71, 72 BI6, BI7, BI8
0122 RO1-3 STATUS 40122 BI4, BI5, BI6 76, 77, 78 BI0, BI1, BI2
0301 FB STATUS WORD – bit 0 (STOP) 40301 bit 0 BI1 23 BV0
0301 FB STATUS WORD – bit 2 (REV) 40301 bit 2 BI2 21 BV
Mailbox Read/Write
The MD5 provides a “Mailbox” function to access parameters
that have not been pre-dened by the protocol. Using mailbox,
any drive parameter can be identied and read. Mailbox can
also be used to adjust parameter settings by writing a value to
any parameter identied. The following table describes the use
of this function.
Table 34: Mailbox Read/Write Parameters
Name Description
Protocol Reference
Modbus1 N2 FLN BACnet
Mailbox Parameter Enter the number of the drive parameter to access. Does not apply. AO19 95 AV25
Mailbox Data
Contains the parameter value after a read, or enter the desired
parameter value for a write.
AO20 96 AV26
Mailbox Read
A binary value triggers a read – the value of the “Mailbox
Parameter” appears in “Mailbox data”.
BO19 97 BV15
Mailbox Write
A binary value triggers a write – the drive value for the
“Mailbox Parameter” changes to the value in “Mailbox data”.
BO20 98 BV16
1. As noted above, Modbus provides direct access to all parameters using the format: 4 followed by the parameter number.
