Table 21 continued: Group 64: Load Analyzer
6411 FREQ AT PEAK 0.0…6553.5 Hz 0.1 Hz —
Output frequency at the moment of the peak value (herzes).
6412 TIME OF RESET 1
Date dd.mm.yy
/ power-on time
in days
1 d —
Last reset date of the peak logger and amplitude logger 2.
• Format: Date if the real time clock is operating (dd.mm.yy). / The number of days elapsed after the power-on if the real time clock is not used,
or was not set (xx d).
6413 TIME OF RESET 2 Time hh.mm.ss 2 s —
Last reset time of the peak logger and amplitude logger 2.
• Format: hours:minutes:seconds.
6414 AL1RANGE0TO10 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 0…10% distribution.
6415 AL1RANGE10TO20 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 10…20% distribution.
6416 AL1RANGE20TO30 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 20…30% distribution.
6417 AL1RANGE30TO40 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 30…40% distribution.
6418 AL1RANGE40TO50 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 40…50% distribution.
6419 AL1RANGE50TO60 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 50…60% distribution.
6420 AL1RANGE60TO70 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 60…70% distribution.
6421 AL1RANGE70TO80 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 70…80% distribution.
6422 AL1RANGE80TO90 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) 80…90% distribution.
6423 AL1RANGE90TO 0.0…100.0% 0.1% —
Amplitude logger 1 (current in percent of nominal current I2
n
) over 90% distribution.
6424 AL2RANGE0TO10 0.0…100.0% 0.1% —
Amplitude logger 2 (signal selection with parameter 6404) 0…10% distribution.
6425 AL2RANGE10TO20 0.0…100.0% 0.1% —
Amplitude logger 2 (signal selection with parameter 6404) 10…20% distribution.
6426 AL2RANGE20TO30 0.0…100.0% 0.1% —
Amplitude logger 2 (signal selection with parameter 6404) 20…30% distribution.
