Specifications Si33-105
10 Specifications R407C PLUS Series Heat Recovery System
Notes:
"
1 Indoor temp. : 27°C DB or 19°C WB / outdoor temp. : 35°C DB / Equivalent piping length : 7.5m, level
difference : 0m.
"
2 Indoor temp. : 20°C DB / outdoor temp. : 7°C DB or 6°C WB / equivalent piping length : 7.5m, level
difference : 0m.
Model RSEYP26KJY1 RSEYP28KJY1
Constituent Model (Main Unit + Sub Unit) REYP16KJY1+RXEP10KJY1 REYP20KJY1+RXEP8KJY1
Power Supply 3 phase 50Hz 380-415V 3 phase 50Hz 380-415V
"
1 Cooling Capacity kW 71.2 76.6
"
2 Heating Capacity kW 71.2 76.6
Casing Color Ivory white (5Y7.5/1) Ivory white (5Y7.5/1)
Dimensions : (H×W×D) mm (1,460×2,580×690)+(1,440×1,280×690) (1,460×2,580×690)+(1,220×1,280×690)
Heat Exchanger Cross fin coil Cross fin coil
Compressor
Model JT236DCVTYE@2+JT300DATYE@2×2 JT236DCVTYE@2+JT300DATYE@2×2
Type Hermetically sealed scroll type Hermetically sealed scroll type
Piston Displacement m³/h (43.3+28.4+28.4) (43.3+28.4+28.4)
Number of Revolutions rpm (5,510, 2,900, 2,900) (5,510, 2,900, 2,900)
Motor Output × Number
of Units
kW 5.5+7.5+7.5 5.5+7.5+7.5
Starting Method Direct on line Direct on line
Fan
Model P52H11S P52H11S
Type Propellor fan Propellor fan
Motor Output × Number
of Units
kW (0.14+0.23)×2+(0.14+0.23) (0.14+0.23)×2+(0.14+0.23)
Air Flow Rate m³/min 510 490
Drive Direct drive Direct drive
Connecting
Pipes
Outdoor Unit
Liquid
pipe
φ
22.2 C1220T (Brazing connection)
φ
22.2 C1220T (Brazing connection)
Gas
pipe
φ
41.3 C1220T (Brazing connection)
φ
41.3 C1220T (Brazing connection)
Discharge
pipe
φ
28.6 C1220T (Brazing connection)
φ
34.9 C1220T (Brazing connection)
Main Unit ~ Sub Unit
Liquid
pipe
φ
12.7 C1220T (Flare-Brazing connection)
φ
12.7 C1220T (Flare-Brazing connection)
Gas
pipe
φ
28.6 C1220T (Brazing-Brazing connection)
φ
28.6 C1220T (Brazing-Brazing connection)
Weight kg 640+105 640+95
Safety Devices
High pressure switch, fan motor safety thermostat, inverter
overload protector, overcurrent relay, fusible plugs
High pressure switch, fan motor safety thermostat, inverter
overload protector, overcurrent relay, fusible plugs
Defrost Method Deicer Deicer
Capacity Control % 11 ~ 100 11 ~ 100
Refrigerant
Refrigerant Name R407C R407C
Charge kg 29.5 29.5
Control Electronic expansion valve Electronic expansion valve
Refrigerator
Oil
Refrigerant Oil DAPHNE FVC68D DAPHNE FVC68D
Charge Volume L 4.0+4.0+4.0 4.0+4.0+4.0
Standard Accessories
Accessories pipe (Gas, liquid and Discharge pipe),
Connection pipes (Gas pipe), Installation manual,
Operation manual, Jumper wire (Low, High voltage),
Clamps
Accessories pipe (Gas, liquid and Discharge pipe),
Connection pipes (Gas pipe), Installation manual,
Operation manual, Jumper wire (Low, High voltage),
Clamps
To Next Page
