Specifications Si33-105
22 Specifications R407C PLUS Series Heat Recovery System
Ceiling Mounted Duct Type
Notes:
"
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
"
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
"
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
"
4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means “High Static pressure-Standard-Low static pressure”.
"
5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colorimetric method (gravity method) 50% or more.
Model FXYMP100KV1 FXYMP125KV1 FXYMP200KV1 FXYMP250KV1
Power Supply
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
"
""
"
1 Cooling Capacity kW 11.2 14.0 22.4 28.0
"
""
"
2 Heating Capacity kW 12.5 16.0 25.0 31.5
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 390×1,110×690 390×1,110×690 470×1,380×1,100 470×1,380×1,100
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×16×2.0 3×16×2.0 3×26×2.0 3×26×2.0
Face Area m² 0.319 0.319 0.68 0.68
Fan
Model 2D11/2D3AG1VE 2D11/2D3AF1VE D13/4G2AD1×2 D13/4G2AD1×2
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 270 430 380×2 380×2
Air Flow Rate (H/L) m³/min 29/23 36/29 58/50 72/62
External Static Pressure Pa 157/98
"
""
"
4 191/152
"
""
"
4 221-132
"
""
"
5 270-191
"
""
"
5
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber Glass Fiber
Air Filter
"
""
"
5
"
""
"
5
"
""
"
5
"
""
"
5
Piping
Connections
Liquid Pipes 9.5mm (Flare Connection) 9.5mm (Flare Connection) 12.7mm (Flare Connection) 12.7mm (Flare Connection)
Gas Pipes 19.1mm (Flare Connection) 19.1mm (Flare Connection)
25.4mm
(Brazing Connection)
28.6mm
(Brazing Connection)
Drain Pipe (mm)
VP25 (External Dia. 32
Internal Dia. 25)
VP25 (External Dia. 32
Internal Dia. 25)
PS1B PS1B
Weight kg 63 65 137 137
Safety Devices
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Sealing
Pads, Connection Pipes,
Screws, Clamps.
Operation Manual,
Installation Manual, Sealing
Pads, Connection Pipes,
Screws, Clamps.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
