Si33-105 Specifications
Specifications R407C PLUS Series Heat Recovery System 23
Ceiling Suspended Type
Notes:
"
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
"
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
"
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Model FXYHP32KV1 FXYHP63KV1 FXYHP100KV1
Power Supply
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
"
""
"
1 Cooling Capacity kW 3.6 7.1 11.2
"
""
"
2 Heating Capacity kW 4.0 8.0 12.5
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 188×1,100×600 188×1,300×600 238×1,300×695
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.75 3×10×1.75 3×12×1.75
Face Area m² 0.181 0.223 0.268
Fan
Model V1 3D12J1AA1VE 4D12J1AA1VE 3D15J1AA1VE
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 57 57 130
Air Flow Rate (H/L) m³/min 13/10 19/15 27/21
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes 6.4mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection) 15.9mm (Flare Connection) 19.1mm (Flare Connection)
Drain Pipe (mm)
VP20 (External Dia. 26
Internal Dia. 20)
VP20 (External Dia. 26
Internal Dia. 20)
VP20 (External Dia. 26
Internal Dia. 20)
Weight kg 27 31 38
Safety Devices
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Fuse
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers, Flare
Nut.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Clamps, Washers.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
