Specifications Si33-105
24 Specifications R407C PLUS Series Heat Recovery System
Wall Mounted Type
Notes:
"
1 Nominal cooling capacities are based on the following conditions:
Return air temperature : 27°C DB, 19°C WB, Outdoor temperature : 35°C DB
Equivalent ref. piping : 5m (Horizontal)
"
2 Nominal heating capacities are based on the following conditions:
Return air temperature : 20°C DB, Outdoor temperature : 7°C DB, 6°C WB
Equivalent ref. piping : 5m (Horizontal)
"
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Model FXYAP20KV1 FXYAP25KV1 FXYAP32KV1
Power Supply
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
1 phase 50Hz
220-240V
"
""
"
1 Cooling Capacity kW 2.2 2.8 3.6
"
""
"
2 Heating Capacity kW 2.5 3.2 4.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 360×1,050×200 360×1,050×200 360×1,050×200
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×12×1.4 2×12×1.4 2×12×1.4
Face Area m² 0.169 0.169 0.169
Fan
Model QCL1165M QCL1165M QCL1165M
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output × Number
of Units
W23 23 23
Air Flow Rate (H/L) m³/min 8/6.5 8/6.5 9/7
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene/ Foamed
Polyethylene
Foamed Polystyrene/ Foamed
Polyethylene
Foamed Polystyrene/ Foamed
Polyethylene
Air Filter Resin Net (Washable) Resin Net (Washable) Resin Net (Washable)
Piping
Connections
Liquid Pipes 6.4mm (Flare Connection) 6.4mm (Flare Connection) 6.4mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection) 12.7mm (Flare Connection) 12.7mm (Flare Connection)
Drain Pipe (mm)
VP20 (External Dia. 26
Internal Dia. 20)
VP20 (External Dia. 26
Internal Dia. 20)
VP20 (External Dia. 26
Internal Dia. 20)
Weight kg 21 21 21
Safety Devices
Fuse
Thermal Protector for Fan Motor
Fuse
Thermal Protector for Fan Motor
Fuse
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Insulation for Fitting, Screws, Clamps,
Insulation Tape, Installation Panel
Fixed Parts.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Insulation for Fitting, Screws, Clamps,
Insulation Tape, Installation Panel
Fixed Parts.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Insulation for Fitting, Screws, Clamps,
Insulation Tape, Installation Panel
Fixed Parts.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
