dallmeier DF4510H - Dome Cameras; In-Ceiling Mount Variants (IM)

DF4510HD | DF4910HD | DDF4510HDV-IM/-SM | DDF4910HDV-IM/-SM
www.dallmeier.com 100
19.2 Dome Cameras
19.2.1 In-ceiling Mount Variants (IM)
134.70 mm (5.30")
142 mm (5.59")
114.60 mm (4.51")
170 mm (6.69")
Fig. 19-3
60 mm (2.36")
14 mm (0.55")
62 mm (2.44")
28.80 mm
41.50 mm
(1.63")
(1.13")
Fig. 19-4
