19 Technical Drawings
The following technical drawings were valid at the time of this document’s compilation.
Visit www.dallmeier.com for possible updates.
19.1 Box Cameras
71 mm (2.8")
66 mm (2.6")
Fig. 19-1
113 mm (4.45")
5.5 mm (0.22")17 mm (0.67")
Fig. 19-2
