5.2 Dome Cameras
5.2.1 In-ceiling Mount Variants (IM)
Thread for M6 screw eye bolt
Housing
Trim ring with bubble
3-axis mount
(pan / tilt / rotation)
Thread for PG16 cable gland
Lens
Ceiling clamp
Housing screw
(T20 Torx)
Black inner
dome cover
Fig. 5-3
NOTICE
Always ensure that the lens is not covered by the black inner dome cover
when assembling the camera enclosure.
