81 Piranha 2 User’s Manual
03-032-00493-14 Teledyne DALSA
Appendix E
Revision History
Updated pgs 9-10: Added sensor alignment specifications of x,y: ±175um, z:
±0.18mm and ø: 0.6°. Changed FPN uncorrected: Max Gain 27DN. Changed
RMS Noise: typ. 1.2DN, max 4DN. Added Notes: All measurements taken in 8-
bit output mode; All specifications are valid for the front plate temperature
range of 10°C to 50°C, in still air. Added Notes 4 and 5.
Page 25,26 Mechanicals drawings: Included specifications on the location of
pixel 1 with respect to edges of the front plate. On page 27 removed nominal
from C, F-Mount chart and replaced with ±0.18mm
1K, 2k, and 4K--2 tap Piranha 2 cameras available.
Mostly minor text and spec changes, plus replacing Doody with Helmond on
EMC declaration
Added note 4 on page 10.
Added section 3.10, page 27, Setting a Region of Interest.
Added section 3.11, page 27, Returning Video Information.
Removed all references of the css command default being 128 and changed it to
64.
On page 31, Calibrating Gains, changed allowable ranges from 64 (was 128) to
251 and 256 (was 512) to 1007.
Added error message 28 and 29 on page 64. Removed error message 20.
Added informal message codes 32 and 64 on page 65.
Added section C6 Camera Parameter Screen on page 65.
In section C7, command table:
cag: range is now 64 (was 128) to 251 or 256 (was 512) to 1007
ccp: range is now 64 (was 128) to 251 or 256 (was 512) to 1007
css: 64 is now the factor setting. 128 was removed.
roi: explanation expanded to include the roi influence on the cag, cao, gl, gla,
ccf and ccp commands.
Added P2x-xxx30 part number to front cover.
Added 30MHz info to section 1.1 Camera Highlights.
Added 30MHz specs to section 1.3 Camera Performance Specifications
Added Note 1 on page 10
Added table 5, page 20, 30MHz timing values
Added P2-2x-xxx30 to EMC Declaration of Conformity, page 61.
Updated drawing in section 2.2. LED was referenced to section D13 which no
longer exists. It is now referenced to section 3.18.
In section 3.16, page 39, and Appendix B, All Available Commands table, added
equation for determining the PRNU coefficient for the spc command.
