D&R AXUM - Page 113

A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 113 -
Function name
Comments
Object to connect to
Version
Ext 5 off
Deselect Ext 5 for the monitor buss
Switch
2.2
Ext 5 on/off Toggle Ext 5 for the monitor buss Switch
2.0
Ext 6 on
Select Ext 6 for the monitor buss
Switch
2.2
Ext 6 off
Deselect Ext 6 for the monitor buss
Switch
2.2
Ext 6 on/off Toggle Ext 6 for the monitor buss Switch
2.0
Ext 7 on
Select Ext 7 for the monitor buss
Switch
2.2
Ext 7 off
Deselect Ext 7 for the monitor buss
Switch
2.2
Ext 7 on/off
Toggle Ext 7 for the monitor buss
Switch
2.0
Ext 8 on
Select Ext 8 for the monitor buss
Switch
2.2
Ext 8 off
Deselect Ext 8 for the monitor buss
Switch
2.2
Ext 8 on/off
Toggle Ext 8 for the monitor buss
Switch
2.0
Mute Mutes the output GPO, CRM mute 2.0
Dim
Dims the output
CRM level
2.0
Phones level
Controls the level in steps of 0.1 dB
CRM phones level
2.0
Mono Mono the output CRM Mono 2.0
Phase
Phase reverse the right output
CRM Phase
2.0
Speaker level
Controls the level in steps of 0.1 dB
CRM speaker level
2.0
Talkback 1
Talkback to monitor from Talkback 1
Switch
2.0
Talkback 2
Talkback to monitor from Talkback 2
Switch
2.0
Talkback 3
Talkback to monitor from Talkback 3
Switch
2.0
Talkback 4
Talkback to monitor from Talkback 4
Switch
2.0
Talkback 5 Talkback to monitor from Talkback 5 Switch 2.0
Talkback 6
Talkback to monitor from Talkback 6
Switch
2.0
Talkback 7
Talkback to monitor from Talkback 7
Switch
2.0
Talkback 8 Talkback to monitor from Talkback 8 Switch 2.0
Talkback 9
Talkback to monitor from Talkback 9
Switch
2.0
Talkback 10
Talkback to monitor from Talkback 10
Switch
2.0
Talkback 11
Talkback to monitor from Talkback 11
Switch
2.0
Talkback 12
Talkback to monitor from Talkback 12
Switch
2.0
Talkback 13
Talkback to monitor from Talkback 13
Switch
2.0
Talkback 14
Talkback to monitor from Talkback 14
Switch
2.0
Talkback 15 Talkback to monitor from Talkback 15 Switch 2.0
Talkback 16
Talkback to monitor from Talkback 16
Switch
2.0
Audio level left
Left audio level of a monitor buss
Level meter
2.0
Audio level right Right audio level of a monitor buss Level meter 2.0
Audio phase
Phase between left and right of a monitor
buss
Phase meter
2.3
Label
Name of the monitor buss
Display
2.0
Select 1
When monitor buss select for console 1 is
activated the current monitor buss will be
selected
meter-selector
2.3
Select 2
When monitor buss select for console 2 is
activated the current monitor buss will be
selected
meter-selector
2.3
Select 3
When monitor buss select for console 3 is
activated the current monitor buss will be
selected
meter-selector
2.3
Select 4
When monitor buss select for console 4 is
activated the current monitor buss will be
selected
meter-selector
2.3
