D&R AXUM - 20.7 Destination Functions List

A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 120 -
Name
comments
Example
object to
connect to
Version
Select 2
When source select for console 2 is activated the source will be
selected
future use
2.3
Select 3
When source select for console 3 is activated the source will be
selected
future use
2.3
Select 4
When source select for console 4 is activated the source will be
selected
future use
2.3
20.7 Destinations
Some objects have functionality that relates to the destination selected on a send module. For
example if you have a GPI that should trigger a TB or MUTE send module function.
This group with destination functions makes it possible to have destination related send module
functionality:
Name
Comments
Example object to connect to
Version
Label
Shows the name of the current destination
Display
2.0
Source
Selects the source for this destination
Encoder/Display
2.0
Monitor speaker level If the source is a monitor buss and the speaker
level is changed this destination will follow
I/O card level 2.0
Monitor phones level If the source is a monitor buss and the phones
level is changed this destination will follow
I/O card level 2.0
Level
This adjust the level of this destination
Encoder
2.0
Mute
Mutes this destination
Switch, I/O card mutes
2.0
Mute & Monitor mute
Mutes this destination if the source is a monitor
buss and the monitor buss mute is activated or its
local mute is set.
I/O card mutes
2.0
Dim
Dims this destination
Switch, I/O card dim
2.0
Dim & Monitor dim Dims this destination if the source is a monitor
buss and the monitor buss dim is activated or its
local dim is set.
I/O card dim 2.0
Mono
Make this destination mono
Switch, I/O card mono
2.0
Mono & Monitor mono Make this destination mono if the source is a
monitor buss and the monitor buss mono is
activated or its local mono is set.
I/O card mono 2.0
Phase Changes phase for this destination Switch, I/O card phase 2.0
Phase & Monitor phase
Changes phase for this destination if the source
is a monitor buss and the monitor buss phase is
activated or its local phase is set.
I/O card phase
2.0
Talkback 1
Do talkback to this destination
Switch, I/O card talkback 1
2.0
Talkback 1 & Monitor
talkback 1
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 1
2.0
Talkback 2
Do talkback to this destination
Switch, I/O card talkback 2
2.0
Talkback 2 & Monitor
talkback 2
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 2
2.0
Talkback 3
Do talkback to this destination
Switch, I/O card talkback 3
2.0
Talkback 3 & Monitor
talkback 3
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 3 2.0
Talkback 4
Do talkback to this destination
Switch, I/O card talkback 4
2.0
Talkback 4 & Monitor
talkback 4
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 4
2.0
Talkback 5 Do talkback to this destination Switch, I/O card talkback 5 2.0
Talkback 5 & Monitor
talkback 5
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 5
2.0
Talkback 6
Do talkback to this destination
Switch, I/O card talkback 6
2.0
Talkback 6 & Monitor
talkback 6
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 6
2.0
Talkback 7
Do talkback to this destination
Switch, I/O card talkback 7
2.0
