A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 121 -
Name
Comments
Example object to connect to
Version
Talkback 7 & Monitor
talkback 7
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 7
2.0
Talkback 8
Do talkback to this destination
Switch, I/O card talkback 8
2.0
Talkback 8 & Monitor
talkback 8
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 8
2.0
Talkback 9
Do talkback to this destination
Switch, I/O card talkback 9
2.0
Talkback 9 & Monitor
talkback 9
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 9 2.0
Talkback 10 Do talkback to this destination Switch, I/O card talkback 10 2.0
Talkback 10 & Monitor
talkback 10
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 10
2.0
Talkback 11
Do talkback to this destination
Switch, I/O card talkback 11
2.0
Talkback 11 & Monitor
talkback 11
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 11
2.0
Talkback 12
Do talkback to this destination
Switch, I/O card talkback 12
2.0
Talkback 12 & Monitor
talkback 12
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 12
2.0
Talkback 13
Do talkback to this destination
Switch, I/O card talkback 13
2.0
Talkback 13 & Monitor
talkback 13
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 13
2.0
Talkback 14
Do talkback to this destination
Switch, I/O card talkback 14
2.0
Talkback 14 & Monitor
talkback 14
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 14 2.0
Talkback 15
Do talkback to this destination
Switch, I/O card talkback 15
2.0
Talkback 15 & Monitor
talkback 15
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 15
2.0
Talkback 16
Do talkback to this destination
Switch, I/O card talkback 16
2.0
Talkback 16 & Monitor
talkback 16
Do talkback to this destination if the source is a
monitor buss and the monitor buss talkback is
activated or its local talkback is set.
I/O card talkback 16
2.0
Routing
Makes it possible to select which channels are
going to this destination. The options are Left,
Right, Stereo
Encoder, Display
2.1
Select 1
When destination select for console 1 is activated
the destination will be selected
future use
2.3
Select 2
When destination select for console 2 is activated
the destination will be selected
future use
2.3
Select 3
When destination select for console 3 is activated
the destination will be selected
future use
2.3
Select 4
When destination select for console 4 is activated
the destination will be selected
future use
2.3
