A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 67 -
The value must be between 0 – 250, where 0 is a continuous signal and 1 - 250 is the pulse
width in milliseconds.
When you submit an empty box the object returns to the startup default value.
9.3.5 GPO Active-state
Figure 45: GPO Active-state configuration
• Default
The gray value ‘1’ is the startup default, this may be changed by assigning a custom value (0
or 1). A value of ‘1’ makes sure that if the GPO is active the output is +5V in TTL mode or A/B
connected for relay mode. The value ‘0’ makes sure that if the GPO is active the output is 0V
in TTL mode or A/B disconnected in relay mode.
When you submit an empty box the object returns to the startup default value.
