Function Name
Comments
Object to connect to
Version
Master & control mode buss
17/18
Master control mode & module control mode are
switched to buss 17/18
Switch
2.0
Master & control mode buss
19/20
Master control mode & module control mode are
switched to buss 19/20
Switch
2.0
Master & control mode buss
21/22
Master control mode & module control mode are
switched to buss 21/22
Switch
2.0
Master & control mode buss
23/24
Master control mode & module control mode are
switched to buss 23/24
Switch 2.0
Master & control mode buss
25/26
Master control mode & module control mode are
switched to buss 25/26
Switch 2.0
Master & control mode buss
27/28
Master control mode & module control mode are
switched to buss 27/28
Switch
2.0
Master & control mode buss
29/30
Master control mode & module control mode are
switched to buss 29/30
Switch
2.0
Master & control mode buss
31/32
Master control mode & module control mode are
switched to buss 31/32
Switch
2.0
Console preset label
Returns the name of the last used preset on the
console
Display
2.0
Module select
Function to select a module on the console
Module select encoder
2.3
Selected module active Is active for 10 seconds when a module parameter is
changed
Show module parameters 2.5
Buss select Function to select a buss on the console buss select encoder 2.3
Selected buss active
Is active for 10 seconds when a buss parameter is
changed
Show buss parameters
2.5
Monitor buss select
Function to select a monitor buss on the console
monitor buss select
encoder
2.3
Selected monitor buss active
Is active for 10 seconds when a monitor buss
parameter is changed
Show mon buss
parameters
2.5
Source select
Function to select a source the console
source select encoder
2.3
Selected source active
Is active for 10 seconds when a source parameter is
changed
Show source parameters
2.5
Destination select Function to select a destination on the console destination select encoder 2.3
Selected destination active
Is active for 10 seconds when a destination parameter
is changed
Show dest parameters
2.5
Console chipcard change
Function to detect insertion of a chipcard
chipcard switch
2.3
Console chipcard username
Function to connect to the physical chipcard objects in
a surface
chipcard username
2.3
Console chipcard password
Function to connect to the physical chipcard objects in
a surface
chipcard password
2.3
Console write chipcard
user/pass
Function to connect to the physical chipcard objects in
a surface
- 2.3
Console username Function that updates if the console username on a
change.
external application 2.3
Console password
Function that updates if the console password on a
change.
external application
2.3
Console username/password
Function that updates on account changes or may set
the account of the console
external application
2.3
Console user level
May be used to set the user level of the console, it
also updates when the user level of the console has
been changed
external application
2.3
Second dot count up/down
This function makes it possibly to make de clock
second dots change from count up to count down
Clock application
2.5
Program end time enable
The program end time may be displayed in the clock if
enabled.
Clock application
2.5
Program end time hours
This function may be used to set the hour value of the
program end time.
Clock application
2.5
Program end time minutes
This function may be used to set the minute value of
the program end time.
Clock application
2.5
Program end time seconds
This function may be used to set the second value of
the program end time.
Clock application
2.5
Count down timer
This function may be used to set the count down timer
which may be shown in the clock application
Clock application
2.5
