A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 23 -
• Processing preset
If this source is selected on a module, by the ‘source select’ function (not via module or
console preset), this processing preset is ‘set’ on the module.
• Trigger start
Here you can configure how the source start/stop change is triggered:
- Dedicated, the module fader and on are not triggering start/stop only the dedicated start/stop
controllers.
- Module fader on, the fader on will trigger the start as well.
- Module on, the on switch will trigger the start as well.
- Module fader on & on, the fader must be open and on active then the start is triggered.
Dedicated start/stop objects will work in parallel with these ‘trigger start/stop’ modes
• Trigger stop
Here you can configure how the source start/stop change is triggered:
- Dedicated, the module fader and on are not triggering start/stop only the dedicated start/stop
controllers.
- Module fader off, the fader off will trigger the stop as well.
- Module off, the on switch will trigger the stop as well.
- Module fader off & off, the fader must be closed or on inactive then the stop is triggered.
Dedicated start/stop objects will work in parallel with these ‘trigger start/stop’ modes
• Red-light.
When this source becomes active on a module, the corresponding Red-light buss becomes
active.
• Monitor destination mute
When this source becomes active on a module, the corresponding monitor buss will be muted.
• Related destination
When you give a source a related destination it is possible to use TB functions on the module
and communication features from the GPIOs. For example you will make the relation
announcer microphone to announcer headphone.
• Delete
When you click on this column the source will be deleted (and also all references are deleted).
• Create a new source
By clicking on this link a popup will appear where you have to setup the physical inputs and
label for the new source.
